MPPT SOLAR Charge Controller 45Amp 12V/24V/36V/48VDC Auto Charger MPPT-45A

$355.00  $289.00
Save: 19% off

Always Free Shipping
Add to Cart:

  • Model: MPPT-45A
  • Manufactured by: ROXSAT







A MPPT, or maximum power point tracker is an electronic DC to DC converter that optimizes the match between the solar array (PV panels), and the battery bank or utility grid. To put it simply, they convert a higher voltage DC output from solar panels down to the lower voltage needed to charge batteries.

Key Points:

  • Large size L 17"x W 8"x H 5"
  • Solid built high quality
  • Lots of protections
  • Large heatsink
  • Auto green backlight on/off LCD display
  • Auto Fan on/off
  • PC software
  • Battery temperature monitoring
  • DC voltage input auto detection
  • Fault warning LED
  • Wall mount
  • Solar in, battery in, load out
  • Positive and negative separation wiring
  • Distance wiring to prevent short circuit
  • Large gauge wiring.
  • Charge 2 groups: Lithium and Sealed Lead Acid, AGM/Gel, Nonsealed Lead Acid batteries
  • Adjustable charging voltage and current

About this high quality solar charge controller:

  • MPPT charge controller: 45A MPPT Solar charge controller(Air cooling).
  • High efficiency: MPPT efficiency>99%,Peak conversion efficiency >98%.
  • Multi-stage charging: Multi-stage charging mode.
  • DC load DC load support: 12V/24V/36V/48V auto work.
  • DSP processors: DSP processors architecture ensures high speed and performance.
  • Protection: PV array short circuit , PV reverse polarity , Battery reverse polarity , Over charging , Output short circuit.

You should adjust the battery charging voltage set points according to your battery manufacture suggested charging voltage.

if you don’t have it,  then you can set basic voltage set points following below

Battery Type Voltage Point Setting 12V 24V 48V



Sealed Lead Acid

AGM/Gel

Nonsealed Lead Acid

Absorption Voltage 12.5V 25.0V 50.5V
Refloat Voltage 13.7V 27.4V 54.8V
Float Voltage 14.3V 28.6V 57.2V

Lithium Absorption Voltage 13.2V 26.4V 52.8V
Refloat Voltage 13.4V 26.8V 53.6V
Float Voltage 13.5V 27.0V 54.0V

LCD/LED DISPLAY INFORMATION

  1. MENU: Enter or exit setting mode
  2. UP: Increase the setting data
  3. DOWN: Decrease the setting data
  4. ENTER: Confirm the selection in setting mode
  5. LED indicator System status
    PV Green On PV voltage normal
    Flashing every 1s PV fault is recovering
    Flashing every 2s PV fault can’t recover
    Off PV is off
  6. LED indicator System status
    BATT Yellow On Battery voltage normal
    Flashing every 1s Battery fault is recovering
    Flashing every 2s Battery fault can’t recover
    Off Battery is off
  7. LED indicator System status
    FAULT Red Flashing Fault
    Off Normal
  8. LCD display

FIGURE BACK PANEL INFORMATION

  1. LO+: The load positive terminal
  2. BA+: The battery positive terminal
  3. BA-: The battery negative terminal
  4. LO-: The load negative terminal
  5. PV-: PV array negative terminal
  6. PV+: PV array positive terminal
  7. REM: RS485 Communication network terminal(Use for computer)
  8. BTS: Battery Remote Temperature sensor terminal

SPECIFICATION

Model MPPT-45A MPPT-60A
Default Battery System Voltage 12VDC/24VDC/36VDC/48VDC (Auto Detection)
CONTROLLER INPUT
PV Open Circuit Voltage 100VDC@12V/ 145VDC @24V/ 145VDC @36V/ 145VDC @48V
PV Array MPPT Voltage Range 16VDC~100VDC / 32VDC~130VDC / 48VDC~130VDC / 64VDC~130VDC
Max PV Input Power (12V) 600W 800W
Max PV Input Power (24V) 1200W 1600W
Max PV Input Power (36V) 1800W 2400W
Max PV Input Power (48V) 2400W 3200W
BATTERY
Peak Conversion efficiency 98% (MPPT Efficiency 99%)
Max Charging Current 45 amps continuous 60 amps continuous
Absorption Voltage 12.5VDC/25.0VDC/37.5VDC/50.0VDC
Refloat Voltage 13.7VDC/27.4 VDC/41.4VDC/54.8VDC
Float Voltage 14.3VDC/28.6 VDC/42.9VDC/57.4VDC
Low Voltage Protection Point 10VDC/20.0 VDC/30.0VDC/40.0VDC
DC OUTPUT
Output Voltage 10.0VDC~14.5VDC / 20VDC~29.0VDC / 30.0VDC~43.5VDC / 40.0VDC~58.0VDC
Max Load Current 45 amps continuous 60 amps continuous
Warning for low voltage 10.25VDC/20.5 VDC/30.75VDC/41.0VDC
Cut off for low voltage 10.0VDC/20.0 VDC/30.0VDC/40.0VDC
Low voltage recovery 11.0VDC/22.0 VDC/33.0VDC/44.0VDC
GENERAL SPECIFICATION
Radiating mode Air cooling
DISPLAY & PROTECTION
LED indication Systematic operation, LV indication, LV protection, over charge protection, loads protection, short circuit protection
LCD display Charge voltage, charge current, voltage of storage battery, capacity of storage battery, output current
Alarm Protections PV array short circuit, PV reverse polarity;Battery reverse polarity, Over charging protection;Output short circuit protection;Low voltage protection for storage battery.
MECHANICAL SPECIFICATIONS
Mounting Wall mount
W*H* D(mm)/Net Weight(kg) 205x 371.7x 124.3 mm / 6.45kg
8.07x 16.36x 4.89 Inch  / 14.33Lb
OTHER
Environmental Rating Indoor
Operation Temperature Range -25~+55°C
Ambient humidity 0~90% relative humidity(non-condensing)
Altitude ≤ 3000m
